| Place of Origin: | China |
| Brand Name: | Jwell |
| Certification: | ISO CE UL TUV |
| Competitive advantage: | High quality, high capacity, high stability, worldwide after-sales service, more than 30 years developing experience |
This line is suitable for crushing and cleaning of various plastics,such as PP, PE, PS, ABS, and PC,etc.
JWELL QX series washing line is designed for kinds of soft and rigid PP PE plastic,such as film, pipe, thick plate, jerry can, Trash and etc.
We can customized the washing line according to your waste plastic.
The capacity can be 500-3500kg/h.
| No. | Item | KW | Total power（KW） | Qty(pcs) | Model | Security Level |
| 1 | Single shaft shredder | 71 | 71 | 1 | DYSS1000 | IP54 |
| 2 | Conveying Machine | 1.5 | 1.5 | 1 | NMRV75-25-Y1.5-B3 | IP54 |
| 3 | Water Crusher | 90 | 90 | 1 | 280M-04 | IP54 |
| 4 | Crusher horizontal discharge Auger | 3 | 2 | 1 | BWD3-9-3 | IP54 |
| 5 | Drainage Spiral Feeder | 3 | 2 | 1 | BWD3-9-3 | IP54 |
| 6 | Spiral Feeder | 18.5 | 18.5 | 1 | 180M-04 | IP54 |
| 7 | Rinse separation tank (A) 【scraper conveyor】 | 0.75 | 5.25 | 7 | NMRV75-100-Y0.75-TA-B3 | IP54 |
| 8 | Drainage Spiral Feeder | 3 | 1 | 1 | BWD3-9-3 | IP54 |
| 9 | Rinse separation tank (B)【scraper conveyor】 | 0.75 | 5.25 | 7 | NMRV75-100-Y0.75-TA-B3 | IP54 |
| 10 | Drainage Spiral Feeder | 3 | 6 | 2 | BWD3-9-3 | IP54 |
| 11 | Squeezing and drying machine | 132 | 264 | 2 | 315M-04 | IP54 |
| 12 | Electrical power | 7.5 | 15 | 2 | 132M-04 | IP54 |
